600 Series 6" Oval Clear/Amber Warning Light (Grommet Mount, 3-Wire Connection)
Part Number: 100WA0014
Description
600 Series 6-inch Oval Warning Light, Clear Lens / Amber LED, with Grommet Mount, Bare 3-Wire
This light can be wired to sync with 400 Series or 600 Series bare-wire warning lights for a maximum of 8 synchronized lights.
Previous series name: Michigan 6″ Oval
Resources
Specifications
| Voltage | 9–16 VDC |
| Function | Warning light |
| LED Color | Amber |
| Lens Color | Clear |
| Length | 7.44" |
| Width | 3.21" |
| Height | 1.06" |
| Connection | Bare 3-Wire |
| Mounting | Grommet |
| Amps | 460/570mA (min/max) |
| Material | Polycarbonate |
| LED Count | 20 |
| Flash Pattern Qty | 8 |
| Certifications | SAE J595 Class 1 |
| Warranty | 3-year |
